Samples：
T-shirt bag U&W
Type | HBL-500 |
Bag Making Speed | 20-160pcs /min |
Bag Width | 100-300mm |
Bag Length | 200-1200mm |
Bag-Making Thickness | 30-120g |
Power Supply | 220V |
Total Power | 9KW |
Overall Dimension （L*W*H） | 5.3×1.65×2.1m |
Weight | 1600kg |
Use:
This machine takes non-woven fabric as raw materials. It can produce non-woven bags of various sizes of non-woven T-shirt bags.
Features:
1. This machine adopts touch screen computer display, PLC computer program which can be edited.
2. Auto meter counting &stopping, could freely setting number.
3. Computer Fixed-length, printing color mark track orientation, Auto-stop when complete.
4. High voltage static processor, Auto constant temperature heating controller.
5. Unwinding magnetic powder tension control with manual, Auto side-correction control.
6. This machine adopt ultrasonic welding of all aspects, bag mouth folding welding, side sealing, once full completed,
fast speed, easy to operate, firm sealing, beautiful and decent.
Product Introduction:
This machine is suitable for non woven fabric material, can fully automatic make non woven t-shirt bag with
different bag type and size
Samples：
T-shirt bag U&W
Type | HBL-500 |
Bag Making Speed | 20-160pcs /min |
Bag Width | 100-300mm |
Bag Length | 200-1200mm |
Bag-Making Thickness | 30-120g |
Power Supply | 220V |
Total Power | 9KW |
Overall Dimension （L*W*H） | 5.3×1.65×2.1m |
Weight | 1600kg |
Use:
This machine takes non-woven fabric as raw materials. It can produce non-woven bags of various sizes of non-woven T-shirt bags.
Features:
1. This machine adopts touch screen computer display, PLC computer program which can be edited.
2. Auto meter counting &stopping, could freely setting number.
3. Computer Fixed-length, printing color mark track orientation, Auto-stop when complete.
4. High voltage static processor, Auto constant temperature heating controller.
5. Unwinding magnetic powder tension control with manual, Auto side-correction control.
6. This machine adopt ultrasonic welding of all aspects, bag mouth folding welding, side sealing, once full completed,
fast speed, easy to operate, firm sealing, beautiful and decent.
Product Introduction:
This machine is suitable for non woven fabric material, can fully automatic make non woven t-shirt bag with
different bag type and size
